Perkins 1103A-33TG Diesel Genset Engine
FD-1103A-33TG-PNR
Perkins 1100 Series
The Perkins 1103A-33T is a Diesel Engine purpose-built to drive electric generators, delivering steady, reliable RPM performance to keep standby and prime power systems running smoothly. It is a 3 Cylinder Perkins 1100 Series Engine with Turbocharged Aspiration, 3.3 L Displacement, and Direct Injection. Fuel Optimised Emissions Standards. Please Call or Fill out a Quote Form with your Build List, Serial Number, or Engine Model & Application today. It ships as a fully dressed engine including a complete fuel system, 12V starter and alternator, water pump, flywheel, and flywheel housing.

Price:
$9,000.00
Core Charge:
$2,000.00
Engine Specifications:
- Diesel Genset Engine
- Cylinders: 3
- Rated Speed: 1500/1800 RPM
- Emissions: Fuel Optimised
- Bore: 4.14 in / 105 mm
- Stroke: 5 in / 127 mm
- Displacement: 3.3 L
- Compression Ratio: 17.3:1
- Aspiration: Turbocharged
- Combustion System: Direct Injection
- Rotation: Counter-Clockwise
- Cooling System: Liquid
- Length: 45.28 in / 1150 mm
- Width: 29.93 in / 760 mm
- Height: 51.19 in / 1300 mm
- Dry Weight: 925.942 lbs / 420 kg
- Gross Mechanical Output: 42 - 70 kWm
- Typical Electrical Output: 45-75 kVA (36-60 kWe)
- Alternator Efficiency: 89%
- Switchable: Yes
