Perkins New Replacement Engine
Perkins 1103C-33TG Diesel Genset Engine
FD-1103C-33TG-PNR
Perkins 1100 Series
This Perkins 1103C-33TG Diesel Genset Engine is a 3 Cylinder, Perkins 1100 Series, Turbocharged, 3.3 L Displacement Diesel Engine with Direct Injection that is built to fit Diesel Generator Sets. Please Call or fill out a Quote Form with your Build List, Serial Number, or Engine Model & Application today. It ships as a fully dressed engine including: Complete fuel system, 12V starter and alternator, water pump, flywheel, and housing.
Engine Specifications:
- Diesel Genset Engine
- Cylinders: 3
- Rated Speed: 1500/1800 RPM
- Emissions: EU Stage II/U.S. EPA Tier 2
- Bore: 4.14 in / 105 mm
- Stroke: 5 in / 127 mm
- Displacement: 3.3 L
- Compression Ratio: 18.23:1
- Aspiration: Turbocharged
- Combustion System: Direct Injection
- Rotation: Counter-Clockwise
- Cooling System: Liquid
- Length: 41.15 in / 1045 mm
- Width: 24.85 in / 631 mm
- Height: 37.45 in / 951 mm
- Dry Weight: 751.776 lbs / 341 kg
- Gross Mechanical Output: 42 - 52 kWm
- Typical Electrical Output: 46-59 kVA (37-47 kWe)
- Alternator Efficiency: 90%
- Switchable: No
Similar New Engines:
Remans Like This Engine:
Perkins 1104D-44T/TA - NR Builds Remanufactured Diesel Engine
