Perkins New Replacement Engine
Perkins 1104A-44TG Diesel Genset Engine
FD-1104A-44TG-PNR
Perkins 1100 Series
This Perkins 1104A-44TG Diesel Genset Engine is a 4 Cylinder, Perkins 1100 Series, Turbocharged, 4.4 L Displacement Diesel Engine with Direct Injection that is built to fit Diesel Generator Sets. Please Call or fill out a Quote Form with your Build List, Serial Number, or Engine Model & Application today. It ships as a fully dressed engine including: Complete fuel system, 12V starter and alternator, water pump, flywheel, and housing.
Engine Specifications:
- Diesel Genset Engine
- Cylinders: 4
- Rated Speed: 1500/1800 RPM
- Emissions: Fuel Optimised
- Bore: 4.14 in / 105 mm
- Stroke: 5 in / 127 mm
- Displacement: 4.4 L
- Compression Ratio: 17.25:1
- Aspiration: Turbocharged
- Combustion System: Direct Injection
- Rotation: Counter-Clockwise
- Cooling System: Liquid
- Length: 48.86 in / 1241 mm
- Width: 24.77 in / 629 mm
- Height: 37.45 in / 951 mm
- Dry Weight: 1020.74 lbs / 463 kg
- Gross Mechanical Output: 59.6 -94.5 kWm
- Typical Electrical Output: 65-100 kVA (52-80 kWe)
- Alternator Efficiency: 89%
- Switchable: Yes
