Perkins New Replacement Engine
Perkins 1104D-44T Diesel Power Unit
FD-1104D-44T-PU-PNR
Perkins 1100 Series
NL Builds
This Perkins 1104D-44T Diesel Power Unit is a 4 Cylinder, Perkins 1100 Series, Turbocharged, 4.4 L Displacement Diesel Engine with Direct Injection that is built for Industrial Diesel Power Units. Please Call or fill out a Quote Form with your Build List, Serial Number, or Engine Model & Application today.
Engine Specifications:
- Diesel Power Unit
- Cylinders: 4
- Maximum Power: 66 kW
- Maximum Torque: 392 Nm @ 1400 RPM
- Rated Speed: 2200 RPM
- Minimum Power: 58.5 kW
- Emissions: UN ECE R96 Stage IIIA
- Cycle: 4 Stroke
- Bore: 105 mm
- Stroke: 127 mm
- Displacement: 4.4 L
- Compression Ratio: 18.2:1
- Aspiration: Turbocharged
- Combustion System: Direct Injection
- Rotation: Counter-Clockwise
- Cooling System: Liquid
- Length: 1277 mm
- Width: 687 mm
- Height: 965 mm
- Dry Weight: 536 kg
