Perkins New Replacement Engine
Perkins 1104D-44TA Diesel Power Unit
FD-1104D-44TA-PU-PNR
Perkins 1100 Series
NM Builds
This Perkins 1104D-44TA Diesel Power Unit is a 4 Cylinder, Perkins 1100 Series, Turbocharged Aftercooled, 4.4 L Displacement Diesel Engine with Direct Injection that is built for Industrial Diesel Power Units. Please Call or fill out a Quote Form with your Build List, Serial Number, or Engine Model & Application today. It ships as a fully dressed engine including: Complete fuel system, 12V starter and alternator, water pump, flywheel, and housing.
Engine Specifications:
- Diesel Power Unit
- Cylinders: 4
- Maximum Power: 77 kW
- Maximum Torque: 418 Nm @ 1400 RPM
- Rated Speed: 2200 RPM
- Minimum Power: 68.5 kW
- Emissions: UN ECE R96 Stage IIIA
- Cycle: 4 Stroke
- Bore: 4.14 in / 105 mm
- Stroke: 5 in / 127 mm
- Displacement: 4.4 L
- Compression Ratio: 18.2:1
- Aspiration: Turbocharged Aftercooled
- Combustion System: Direct Injection
- Rotation: Counter-Clockwise
- Cooling System: Liquid
- Length: 49.61 in / 1260 mm
- Width: 28.9 in / 734 mm
- Height: 37.96 in / 964 mm
- Dry Weight: 1250.02 lbs / 567 kg
